Compatible case size	Other
Outline drawing	57Wx37Hx147D
Weight	0.22 kg typ
Input Voltage	AC	85-264V
Efficiency	AC	72% typ(AC100V)/73% typ(AC200V)
Power factor
Input changeover system	Worldwide
Safety	UL/CSA60950(UL/cUL)
High frequency current regulation
EMI standard (Input feedback noise)	VCCI,FCC part15,CISPR 22,EN55022 Class B compliant
CE marking
EMS immunity	Electrostatic discharge: EN61000-4-2 compliant Radiate, radio frequency electromagnetic fields: EN61000-4-3 compliant Fast transient burst: EN61000-4-4 compliant Lightning surge: EN61000-4-5 compliant Conductive radio frequency electromagnetic fields: EN61000-4-6 compliant Power source frequency magnetic immunity: EN61000-4-8 compliant Voltage dips and fluctuation: EN61000-4-11 compliant
MTBF
Operating temperature	-10 to 60 deg.C
Leakage current	0.2mA typ (AC100V)/0.5mA typ(AC240V)
Cooling systems	Air-cooling without blower
Insulation
Output ground connection	Capacitor ground
Warranty	Three years after delivery; the defective unit shall be repaired or replaced at our cost if defects belong to us.

WH-C05VH-800	Input Harness
WH-C05VH-800-01	Input Harness (Ferrite Core equipped)
WH-C08XH-500	Output harness for OZM-015 Series
