5.4 Power supply monitoring software

The power supply monitoring software provides you with total management of uninterruptible power supply, such as UPS, Nonstop power supply, which is in serial interface connection with Desktop computers, Workstations, or Servers, and automatically shut downs your system in safe at power failure. In addition, it provides saving of other files, power supply management on the network, and alarm and notice at power failure to widely expand function of power supply.
Power supply monitoring program for Nonstop power supply, "NSP Pro series" is Nonstop power supply monitoring service corresponding to Windows95/98/NT/2000/Vista.
This program monitors power supply abnormal status signal coming from Nonstop power supply via RS-232C to serial port, and notice user's application when blackout and low voltage of battery occurs, and shuts down your system.

<Shutdown timing diagram>

Figure 5.16 Shutdown timing diagram
Figure 5.16 Shutdown timing diagram

<< Nonstop power supply monitoring software >>

- NSP Pro for Windows 95/98
- NSP Pro for Windows NT
- NSP Pro 2 (Windows 2000/XP/Vista)

Features

- To automatically shut down PCs at blackout
- To monitor power recovery for specific period and resume the task after power recovery (monitoring time is settable at discretion).
- To start up any application and notice (see below) at accident (blackout, power recovery and shutdown start). Notice: execution of script for 95/98, transmission of socket for NT/2000/XP/Vista
- otice of any sound when accident occurs
- To use RS-232C as interface with Nonstop power supply

Photo 5.9 Nonstop power supply monitoring software
Photo 5.9 Nonstop power supply monitoring software
Photo 5.10 Time setting screen (NSP Pro 2)
Photo 5.10 Time setting screen (NSP Pro 2)
Photo 5.11 Configuration settings screen (NSP Pro 2)
Photo 5.11 Configuration settings screen (NSP Pro 2)

<< Corresponding OS and Power supply monitoring software (Shutdown software) >>

Power supply monitoring software depends on OS to use. Table below shows software vs. corresponding OS.

Table 5.6 Corresponding OS listing
Name of OS Support status Note
Windows 95
Windows 98
Controlled by our program NSP Pro for Windows 95/98
Windows NT Controllable by our program or uninterruptible power supply service provided in NT standard. NSP Pro for Windows NT
Windows 2000
Windows NT
Controllable by our program or uninterruptible power supply service provided in 2000/XP standard. NSP Pro 2
Windows Vista Controllable by our program. NSP Pro 2
Linux Controllable by free software Normal operation has been confirmed after evaluation by Linux Slackware3.5J kernel: 2.0.34
DOS Customers need to develop program on their own. For more details, see "How to control Nonstop power supply on DOS."
